Lift Check Valve 1
Check Valves

Lift Check Valve

Price:Quoted by size, pressure rating, body material and configuration
  • Size rangeDN15 – DN200 (1/2″ – 8″)
  • Pressure classASME Class 150 – 900 (PN 20 – PN 150)
  • Body materialWCB / CF8 / CF8M
  • Disc / seat sealing face13Cr / 316 stainless steel
Inquire Now WhatsApp

Our Products

In the lift check valve the disc moves vertically along the seat centreline: forward flow lifts the disc, and on reverse flow the disc drops back onto the seat to seal. The design is compact, sealing is reliable and the closing stroke is short, making the valve suitable for small-diameter high-pressure lines. Vertical installation (flow upward) is normally required so that the disc reseats by gravity. Seating may be metal or soft. The valve is widely used at small-bore pump outlets and in steam and gas lines to prevent reverse flow.

Features

· Vertical lift disc: short stroke, reliable sealing · Compact design for small-diameter high-pressure lines · Vertical installation normally required (flow upward) · Metal or soft seating available · Fast closing for effective backflow protection · Flanged or threaded ends

Technical Specifications

Size range
DN15 – DN200 (1/2″ – 8″)
Pressure class
ASME Class 150 – 900 (PN 20 – PN 150)
Body material
WCB / CF8 / CF8M
Disc / seat sealing face
13Cr / 316 stainless steel
End connection
RF flange / threaded
Temperature range
−29 ~ +425 °C (depending on material)
Design standard
API 594 / ASME B16.34
Installation
Vertical (flow upward)

Applications

For small-bore pump outlets, steam, compressed air and instrument air lines, providing one-way flow control to prevent reverse flow.
